FRONT FORK (PARTS) for Husqvarna 701 SUPERMOTO from 2020

FRONT FORK (PARTS)

1

Fork protection ring 60,1mm

48601948

$8,57 Unit Price incl. VAT

2

Stroke indicator 48mm red

48602007

$8,57 Unit Price incl. VAT

3

AXLE CLAMP L/S WITH TUBE CPL.

48601318S1

$1 214,88 Unit Price incl. VAT

4

AXLE CLAMP R/S WITH TUBE CPL.

48601317S1

$1 159,64 Unit Price incl. VAT

5

Sealkit 48mm SKF black

RP10012

$103,75 Unit Price incl. VAT

6

Screw cap M51x1,5 rebound cpl.

48602039S

$129,99 Unit Price incl. VAT

7

Screw cap M51x1,5 compression

48602040S

$129,99 Unit Price incl. VAT

8

O-ring 46x2 NBR70 siliconized

48600048

$6,43 Unit Price incl. VAT

9

Washer 35x43x2,5 plastic

48600456

$4,27 Unit Price incl. VAT

9

Preload bush 35x43x3,5

48600457

$4,27 Unit Price incl. VAT

9

Washer 35x43x1,5 plastic

48600458

$4,27 Unit Price incl. VAT

10

Fork outer tube 54x530 dt54 db

48601981

$432,43 Unit Price incl. VAT

11

Guide bushing set fork 48mm

R14047

$72,24 Unit Price incl. VAT

12

Adjuster kit screw cap

RP10021

$3,27 Unit Price incl. VAT

13

HH collar screw M8x35 TX40

0025080356

$8,57 Unit Price incl. VAT

14

Cartridge right KTM 690 SM

48601067S1

$1 101,08 Unit Price incl. VAT

15

Cartridge left KTM 690 SMC

48601067S2

$1 101,08 Unit Price incl. VAT

16

SPRING C=5,3 L=450 D=5,5

91410043S

$304,49 Unit Price incl. VAT

17

AH SCREW M10X20 SET

00501020S1

$23,99 Unit Price incl. VAT

18

Sticker set APEX OC 90x40

52000210SET

$101,72 Unit Price incl. VAT

19

Washer 32x42x2,5 plastic

48600113

$23,21 Unit Price incl. VAT

97

FORK OIL SAE4 5L

48601166S1

$312,30 Unit Price incl. VAT

98

Fuchs grease IPR (250g)

T14034

$72,21 Unit Price incl. VAT

Find the detailed FRONT FORK (PARTS) HUSQVARNA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original HUSQVARNA part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
