REAR WHEEL

WIRING HARNESS FOR HUSQVARNA SVARTPILEN 2023

BATTERY

Item numbers

HARNESS WIRING

28211175000

Contact

HORN

28111060000

$38,14

Unit Price

HEXAGON COLLAR SCREW M8X16

J900000801600

Contact

HH COLLAR SCREW M6X16 SW8

J025060169

$1,44

Unit Price

ROLLOVER SENSOR

93541088000

$33,91

Unit Price

WASHER M8

J125080006

$4,34

Unit Price

INDICATOR RELAY

90511030000

$41,57

Unit Price

FUSE 10A 07

75011088010

$5,80

Unit Price

FUSE 15A 07

75011088015

$5,80

Unit Price

FUSE 30A

75011088030

$4,34

Unit Price

RELAY (INTERLOCK)

90611057000

$34,57

Unit Price

PIGTAIL PH-3 FUEL PUMP

93511084000

$16,88

Unit Price

TRANSIL UNIT

28111096000

$10,81

Unit Price

CABLE RELAY TO MOTOR

90211059000

$26,12

Unit Price

HEX COLLAR SCREW M6X12

J025060122

$1,44

Unit Price

TOOTHED WASHER M6

J797060003

$1,44

Unit Price

MAIN WIRING HARNESS

28611075000

$18,73

Unit Price

FLANGED BOLT M6X30 WS10

J025060303

$1,44

Unit Price

CABLE EARTH

28111097000

$27,84

Unit Price

PIGTEIL OIL PRESSURE SWITCH

93038091000

$2,89

Unit Price

WIRING HARNESS TEMPERATUR SENS

93811099000

$11,34

Unit Price

VOLTAGE REGULATOR

28111034000

$248,81

Unit Price

STARTER RELAIS

93011058000

$38,80

Unit Price

RUBBER DAMPER STARTER RELAY

93311058000

Contact

BRACKET MOUNT UNIT ELECTRICAL

28111054000

$12,13

Unit Price

RETAINING CAP, DIAGNOSTICS CON

28111054010

$1,44

Unit Price

SCREW M6X1X9

93008020060

$2,89

Unit Price

SEAT SUPPORT COMPLETE

93007047033

$7,51

Unit Price

BOLT SOKET-M8X1.25XL35XCL8.8XB

J900000803500

$1,44

Unit Price

CABLE EARTH ABS

93042033000

$2,89

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Husqvarna. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Husqvarna, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
